GT-530

GT-530 is an intelligent SMS controller for industry applications with the simple commands and SMS tunnel function, and power can be input by the external power or Li-Battery. It supports UNICODE or 7 bit format for users to implement sending SMS messages with various languages. Applying GT-530, the SMS report can be sent by defined time or DI/counter event trigger. This can be a remote control and alarm system allowing you to use your mobile phone to monitor and control your business from any location. Its alarm facilities provide a flexible way to distribute critical alarm information to any number of mobile phone users. GT-530 can monitor total 10 digital inputs (6 counters). The user can also interrogate the status of I/O through SMS messages. The GT-530 also has 2 Digital output which can be activated via DI trigger or SMS to control the lamps, pumps, heaters etc.

Request For Quotation

    Description

    Application 1 : Signal Alarm and SMS communication

    Application 2: Home security

    Application 3: Remote maintenance

    Application 4: SMS Tunnel Communication

    Application 5: DI Alarm and SMS communication

    Features

    • Support 900/1800/1900 MHz Tri-band frequency
    • Identify ASCII or Unicode SMS Automatically
    • Support max. 140 ASCII Characters
    • Support max. 70 Unicode Characters
    • Built-in ASCII Commands and SMS tunnel Communication Modes
    • Max. 10 Default Phone Numbers
    • Built-in Watch-dog Function
    • Industrial Design with Surge Protection
    • Support SMS setting and control
    • 10 DI (6 Counter), 2 DO, 2 RS-232 port
    • Digital input support NC(normal close)/NO(normal open)/Counter modes
    • Send alarm SMS by DI trigger or exceed Counter preset limits
    • Support simple command to send SMS via RS232
    • Support DC +10 VDC ~ +30 VDC Power Input
    • Supports 3.7 V Li-ion Battery Backup
    • DIN Rail design

    Hardware Specification

    System
    CPU 32 bit Arm7, 72 MHz
    SRAM 32 Kbytes
    Flash Memory 512 Kbytes
    RTC Gives time(sec, min, hour) & date, leap year compensation from 1980 to 2079
    WDT(watchdog) Yes
    Serial ports
    COM2 RS-232 : TxD,RxD,GND for configuration
    COM3 RS-232 : TxD,RxD,GND for communication with other devices
    DIO
    Input 10 Channel ( 6 Counter 5~40Hz + 4 Channel Digital input powered by external power or Li-battery)
    On Voltage : +3.5 ~ 24 VDC
    Off Voltage : +1V max.
    Output D/O :2 Channel Open collector output (100mA@24VDC)
    2 digital output channels
    Output type : Open-Collector (NPN)
    Load Voltage : +24 V max.
    Load Current : 100 mA max.
    GSM/GPRS system
    GPRS/GSM GPRS/GSM Tri-Band 900/1800/1900 MHz
    GPRS multi-slot : class 10/8
    GPRS mobile station : class B
    Compliant to GSM phase 2/2+
    -Class 4(2W @ 900 MHz)
    -Class 1(1W @ 1800/1900 MHz)
    Coding schemes : CS 1, CS 2,CS 3,CS 4
    SMS: Text and PDU mode
    Power
    Protection Reverse polarity protection
    Frame Ground Protection ESD, Surge, EFT, Hi-Pot
    Required Supply Voltage +10 VDC ~ +30 VDC
    with 600 mAh Li-ion battery backup
    Power Consumption Idle: 25 mA @ 24 VDC; Data Link: 35 mA @ 24 VDC; Peak: 52 mA @ 24 VDC; Sleep: 30 mA @ 3.7 VDC
    Mechanical
    Casing Plastic
    Flammability UL 94V-0 materials
    Dimensions (W x L x H) 91 mm x 132 mm x 52 mm
    Installation DIN-Rail
    Environmental
    Operating Temperature -25 ℃ ~ +55 ℃
    Storage Temperature -40 ℃ ~ +80 ℃
    Ambient Relative Humidity 5 ~ 95% RH, non-condensing

    Support SMS DBS

    SMS Monitor/Database System Software Solution for GT-53x series

    Ordering Information

    GT-530 CR
    Intelligent SMS Alarm Controller (RoHS)
