Features
- Support Intel Celeron J6412/Core i5/i7 processors
- Support TPM2.0 for Windows 11 OS
- Support 9～36V wide-voltage input
- Support 2*RS232/422/485 COM, max 6*COM Optional
- Support 2*Intel LAN, 4*LAN Optional,
- Compatible with embedded, desktop, wall-mounted, VESA Standards
- Full flat front panel, IP65 level protection
Description
| Model | AXPPC-156A |
| Processor | Intel Celeron J6412 (4 Cores / 4 Threads 2.0GHz, Max turbo 2.6GHz) Intel Core i3-10110U (2 Cores / 4 Threads 2.1GHz, Max turbo 4.1GHz) Intel Core i5-10310U (4 Cores / 8 Threads 1.7GHz, Max turbo 4.4GHz) |
| Memory | Support 1*DDR4 SODIMM memory slot, Max. 32GB |
| BIOS | AMI UEFI BIOS |
| Display Chip | Integrated Intel Graphics |
| Display Port | 1 VGA, 1 HDMI, 1 LVDS (Support synchronous / asynchronous dual display) |
| Storage | Support 1*mSATA (According To The Selected Motherboard) |
| Expansion Slot | Support 1*Mini PCIE slot(support WIFI/BT/3G/4G,with SIM card slot) |
| I/O | 1*HDMI, 2*COM (COM1, 2 RS232/422/485 Optional, 6*COM Optional),
1*Power Switch, 4*USB3.0 (J6412 with 4*USB3.0 + 2*USB2.0), 1*2Pin phoenix connector, 1*Speaker & Mic 2*Intel 1000M LAN (4*LAN Optional), (J6412 with 2*Intel 1000M LAN+1*Intel 2.5G LAN) |
| LCD | Size: 15.6 Inch TFT-LCD; Brightness: 400 cd/㎡; Ratio: 16:9; Resolution: 1920 * 1080 |
| Touch Screen | Multi-Point Capacitive Touch Screen, Lifetime: more than 50 million times; The LCD is fitted with full fit technology |
| Speaker | Two 8-ohm 2-watt speaker |
| Input Voltage | DC 12V |
| Application | Industrial Automation, Medical, Logistics Transportation, Warehousing, Electronic Education and other fields |
| Structure Parameter | |
| Color | Gray |
| Material | Aluminum Alloy + Steel Plate |
| Dimension | 384 * 234 * 48 mm |
| Weight | 3.6 kg |
| Environmental Parameter | |
| Work Temp | 0℃ ～ +50℃, Surface air flow |
| Work Humidity | 5% ～ 95% non-condensing |
