ICO300-MI

Robust DIN-rail Fanless Embedded System with Intel® Atom™ Processor E3815 as an Intel® IoT Gateway Solution

Features

  • Supports Intel® IoT Gateway Technology with Wind River Intelligent Device Platform XT 3.1
  • Fanless and robust design
  • Intel® Atom™ processor E3815 (1.46 GHz)
  • 4 RS-232/422/485 ports
  • 2 isolated 10/100/1000 Mbps Ethernet ports
  • Supports wireless (3G/GPRS)
  • CompactFlash™ (or mSATA) and SATA SSD (or HDD)
  • Wide operating temperature range from -20°C to +70°C
  • 12-24 VDC wide range power input
  • RTC battery support

Introduction

The ICO300-MI based on Intel® Gateway Technology has been upgraded with Wind River Intelligent Device Platform XT v3.1. The reliable din-rail embedded IoT gateway platform utilizes the low power Intel® Atom™ processor E3815 and supports DDR3L system memory maximum up to 4GB, delivering high performance and low power consumption. It provides enterprise-grade security and intelligent manageability, yet simplifies the development process and gateway deployment for IoT applications. The intelligent ICO300-MI is a perfect solution for industrial IoT applications such as smart energy, smart factory automation, facility monitoring systems and more.

Request For Quotation


    Category:

    Description

    CPU
    • Intel® Atom™ processor E3815 (1.46 GHz)
    Chipset
    • SoC integrated
    System Memory
    • 1 x DDR3L-1066 SO-DIMM, up to 4GB (E3815)
    COM
    • 4 x RS-232/422/485
    USB
    • 2 x USB 2.0
    Ethernet
    • 2 x isolated 10/100/1000Mbps
    PoE
    • N/A
    CANbus
    • N/A
    Digital I/O
    • N/A
    Analog Input
    • N/A
    Display
    • 1 x VGA
    Wireless
    • 1 x Full-size PCI Express Mini Card slot
    • 1 x SIM socket
    • 2 x Antenna
    Storage
    • 1 x CompactFlash™ (or mSATA)
    • 1 x SATA SSD (or HDD)
    Others
    • RTC Battery function
    Power Supply
    • 12-24V DC-In
    • DC Version: OVP, reverse protection
    Watchdog Timer
    • 255 levels, 1 ~ 255 sec.
    Construction
    • Extruded aluminum and heavy-duty steel, IP40
    Operating Temperature
    • -20°C ~ +70°C (-4°F ~ +158°F)
    Relative Humidity
    • 10% ~ 95%
    Vibration
    • 2g@5~500Hz, amplitude 0.35 mm (operation/storage/transport)
    Dimensions
    (W x D x H)
    • 48 x 110 x 155 mm (1.88″ x 4.33″ x 6.1″)
    Weight (net/gross)
    • 1.0 kg (2.2 lb)/1.50 kg (3.3 lb)
    Certifications
    • CE, FCC, UL
    EOS Support
    • Intel® IoT Gateway Technology with Wind River
    • Intelligent Device Platform XT 3.1
    Software Support
    • N/A
    Mounting
    • DIN rail
    • Wall mounting

    Ordering Information

    ICO300-E3815-MI3-DC

    Robust DIN-rail fanless embedded system with Intel® Atom™ processor E3815 1.46 GHz, 4 COM ports and Intel® IoT gateway solution supported (-20°C ~ +70°C)

    CompactFlash™

    4 GB or above (with W.T. CF)

    2.5″ SATA SSD or HDD (with W.T. SSD or HDD)



    DDR3L SO-DIMM

    2 GB-4 GB (with W.T. memory)

    Wall mounting kit



    Wireless (3G/GPRS) module
